Step 1
Size it
Choose the variant and size. The pre-cured immobilizer is soft and mouldable.
For the most common fracture in active people — at the joint most exposed to water and daily use.
Intended uses
- Distal forearm fractures
- Carpal and wrist injuries
- Metacarpal fractures
- Paediatric buckle and minimally displaced distal radius fractures
- Minimally displaced distal radius fractures in adults
- Immobilisation of the forearm after surgery
Caution
- Not to be used where FlexiOH® would contact breached skin
- Align the bone before curing — the shape cannot be adjusted afterwards
- Single patient, single use; a cured immobilizer cannot be reused
United States · PDAC-approved HCPCS codes
L3982, L3984 — as listed in the OrthoHeal USA brochure 2025. Coding and billing are the responsibility of the treating facility; OrthoHeal Inc and its distribution partners can advise.
Sizing
Size chart — Short Arm Immobilizer
In centimetres. The zip and the flexible material add a margin of fit.
| Size | Mid-palm circumference (cm) | Forearm length (cm) |
|---|---|---|
| XXS | 9–11 | 14–18 |
| XS | 11–14 | 18–21 |
| S | 14–17 | 23–26 |
| M | 17–18.5 | 26–29 |
| L | 18.5–22.5 | 29–30 |
| XL | 22.5–24.5 | 30–33 |
| SM | 17–18.5 | 23–27 |
| SL | 18.5–22.5 | 27–29 |
| SXL | 22.5–24.5 | 29–30 |
Application
Size it. Zip it. Cure it.
Step 2
Zip and lock it
Wrap, zip and set the limb. Align the bone now — nothing changes after curing.
Step 3
Cure it. Done.
Three to ten minutes under the RizyCure light. The polymer hardens into a rigid, ventilated shell.
Instructions for patients — recommended
- Daily activities that need minimal mobility; shallow pools and bathtubs
- Clean the skin in the open spaces regularly with a small brush or cotton bud
- A hair-dryer on the cool setting dries trapped moisture
- Elevate the limb to reduce swelling
Not recommended
- Do not touch the outer surface during curing — it can burn
- No heavy lifting or strenuous activity; no unnecessary pressure on the immobilizer
- Do not apply or remove without your orthopaedic practitioner
- Do not peel the foam layer; keep away from fire
